Description
Marine Gearbox 40A possesses functions of speed reduction, ahead and astern clutching and bearing propeller thrust. It is designed of vertically offset and one-stage transmission, featuring in small in volume and light in weight.
Main Data
| Input speed | 750-2000r/min | ||
| Reduction ratio | 2.07、2.96 | Trans. capacity | 0.030kw/r/min |
| 3.44 | 0.025kw/r/min | ||
| Control way | Push-and-pull flexible shaft, electrically | ||
| Rated thrust | 8.8KN | ||
| Center distance | 142mm | ||
| L×W×H | 490×670×620mm | ||
| Net weight | 225kg | ||
| Flywheel | 4110C、SAE14、11.5 | ||
| Bell housing | 4110C、SAE1、2、3 | ||
Applications
Marine Gearbox 40A is suitable for medium and small fishing, transport, traffic and passenger boats.
